Product code 71814800
Always creating the highest quality products defines our approach to design, manufacturing and performance. ‘Made by Hansgrohe’ is your assurance of quality.
Please always observe the safety and installation information for your product. You find these details within the assembly instructions.
Item no. | DescriptionProduct code |
---|
1 | handle93336800 |
2 | screw cover96338000 |
3 | flange97995800 |
4 | nut97996000 |
5 | O-ring 41x298212000 |
6 | cartridge, assy92730000 |
7 | locking screw for handle95140000 |
8 | seal95008000 |
9 | set of non return valves DW 1597350000 |
10 | handspray93350800 |
11 | O-ring 18x1,598231000 |
12 | aerator M24x1 (15 l/min)13913800 |
13 | adapter for cartridge95911000 |
14 | O-Ring 30x298186000 |
15 | locating ring92211000 |
16 | O-Ring 36x2,598190000 |
17 | support97523000 |
18 | fixing set (Ø 34)95049000 |
19 | lever collar97548000 |
20 | weight92500000 |
21 | hose 1,25 m95506000 |
22 | connection hose 600 mm92264000 |
23 | connection hose 900 mm M8x0,75 G3/898758000 |
24 | O-ring 7x1,598422000 |
We endeavour to always provide up-to-date, complete information on our website.
However, we do not assume any liability for the suitability of the information for particular uses.
