Product code 26276670
Always creating the highest quality products defines our approach to design, manufacturing and performance. ‘Made by Hansgrohe’ is your assurance of quality.
The Water Regulations Advisory Scheme (WRAS) is the UK Water Industry's approval scheme. Products approved by the scheme have been shown to comply with the requirements of the Water Supply (Water Fittings) Regulations 1999 and amendments.
Please always observe the safety and installation information for your product. You find these details within the assembly instructions.
| Item no. | DescriptionProduct code |
|---|
| 1 | shower arm93768670 |
| 2 | hollow set screw M5x598446000 |
| 3 | filter packing94246000 |
| 4 | head shower26271670 |
| 5 | tile-matching-disk 7 mm93813670 |
| 6 | extension 100 mm94164670 |
| 7 | pipe 546 mm93769670 |
| 8 | pipe 845 mm93906670 |
| 9 | pipe 945 mm93770670 |
| 10 | pipe 1145 mm93907670 |
| 11 | support, assy93729670 |
| 12 | O-ring 12x298214000 |
| 13 | O-ring 11x298127000 |
| 14 | handshower26270670 |
| 15 | shower hose Isiflex'B 1,60 m28276670 |
| 16 | seal98058000 |
| 17 | handle for thermostat93727670 |
| 18 | nut98913000 |
| 19 | thermostat cartridge98282000 |
| 20 | cartridge for exchanged connections92373000 |
| 21 | handle93731670 |
| 22 | shut off unit with selector98283000 |
| 23 | connecting thread G½93730670 |
| 24 | non return valve (pressure-resistant up to 2 MPa)93136000 |
| 25 | non return valve96737000 |
| 26 | O-ring 16x298133000 |
| 27 | filter packing96922000 |
| 28 | escutcheon Ø 70 mm93718670 |
| 29 | set of S-unions (±12 mm)94140000 |
| 30 | noise reduction96429000 |
We endeavour to always provide up-to-date, complete information on our website.
However, we do not assume any liability for the suitability of the information for particular uses.
