Product code 31285000
Always creating the highest quality products defines our approach to design, manufacturing and performance. ‘Made by Hansgrohe’ is your assurance of quality.
Please always observe the safety and installation information for your product. You find these details within the assembly instructions.
| Item no. | DescriptionProduct code |
|---|
| b | fixation extension 35 mm13898000 |
| a | push-open waste set50105000 |
| 1 | handle95519000 |
| 2 | screw cover96338000 |
| 3 | flange97406000 |
| 4 | nut97209000 |
| 5 | O-Ring 32x298193000 |
| 6 | cartridge, assy92730000 |
| 7 | locking screw for handle95140000 |
| 8 | seal95008000 |
| 9 | adapter for cartridge92845000 |
| 10 | O-Ring 30x298186000 |
| 11 | O-ring 35x292604000 |
| 12 | aerator M24x1 (15 l/min)13913000 |
| 13 | flat seal98749000 |
| 14 | fixing set (Ø 32)13961000 |
| 15 | lever collar97548000 |
| 16 | connection hose 450 mm M8x0,75 G3/897206000 |
| 17 | O-ring 6,6x1,693019000 |
| 18 | handshower and hose32128000 |
| 19 | handshower96907000 |
| 20 | shower holder28331000 |
| 21 | guide98918000 |
| 22 | shower hose 1,60 m28246000 |
| 23 | filter packing94246000 |
| 24 | seal98058000 |
