Product code 72528670
Always creating the highest quality products defines our approach to design, manufacturing and performance. ‘Made by Hansgrohe’ is your assurance of quality.
The Water Regulations Advisory Scheme (WRAS) is the UK Water Industry's approval scheme. Products approved by the scheme have been shown to comply with the requirements of the Water Supply (Water Fittings) Regulations 1999 and amendments.
Please always observe the safety and installation information for your product. You find these details within the assembly instructions.
| Item no. | DescriptionProduct code |
|---|
| a | base body13622180 |
| b | waste50001670 |
| c | adapter for exchanged connections93819000 |
| 1 | handle94648670 |
| 2 | screw cover96338610 |
| 3 | sleeve93053670 |
| 4 | escutcheon Ø 68 mm93052670 |
| 5 | washer97600000 |
| 6 | nut93141000 |
| 7 | O-ring 26x298147000 |
| 8 | cartridge, assy95973001 |
| 9 | locking screw for handle95140000 |
| 10 | seal98865000 |
| 11 | adapter for cartridge95634000 |
| 12 | fixing set97971000 |
| 13 | spout 220 mm94649670 |
| 14 | aerator M24x1 (5 l/min)94364000 |
| 15 | O-ring 18x1,598231000 |
| 16 | escutcheon for spout93987670 |
| 17 | connecting thread G½95626000 |
| 18 | O-ring 13x298128000 |
| 19 | extension set 25 mm for 1362218031971000 |
